HUIYUE (DongGuan City) Automation Equipment Co., Ltd.
Description
KP8117D UV accelerated aging test machine
UV accelerated aging test machine, UV chamber, UV tester, UV light chamber The equipment is mainly used in plastics, paints, rubber material in the simulated sunlight, artificial acceleration test rain, dew environment by. Materials used to evaluate the fading, color change, gloss, cracking, blistering, changes embrittlement, oxidation and so on. Thereby providing a basis for improving product performance improved material formulations.
Standards compliant:
UV accelerated aging test machine, UV chamber, UV tester, UV light chamber irradiance: UVB313 0.6W / m2 UVA340 0.68W / m2 Temperature range: RT 10 ~ 70 ?
UV accelerated aging test machine, UV light chamber details
1. Temperature range: RT 10 ~ 70 ?
2. Humidity range: greater than 90% RH
3. Sample and lamp distance: 50 ± 2mm
4. Distance between the centers of the tube: 70mm
5. Irradiance: UVB313 0.6W / m2 UVA340 0.68W / m2
6. Studio Size: 1170mm × 450 mm × 500 mm
7. Dimensions: 1300mm × 550 mm × 1380 mm
UV accelerated aging test machine security measures
1. Power overload, short circuit protection
2. Ground protection
3. Overtemperature protection
4. Water protection
5. Compression overvoltage, overload protection
6. To protect the device, all alarms are automatically cut off the power, and send voice prompts
UV accelerated aging test machine service commitments
1, free onsite installation, training of operators.
2, the product of one year from the date of delivery of repair kits to users, except in the following cases:
. A demand-side operational errors, malfunctions and damage to human;
b. by the supplier shall not bear other case
3, after the expiration of repair kits provide paid services.
UV accelerated aging test machine, UV chamber, UV tester, UV light chamber The equipment is mainly used in plastics, paints, rubber material in the simulated sunlight, artificial acceleration test rain, dew environment by. Materials used to evaluate the fading, color change, gloss, cracking, blistering, changes embrittlement, oxidation and so on. Thereby providing a basis for improving product performance improved material formulations.
Standards compliant:
UV accelerated aging test machine, UV chamber, UV tester, UV light chamber irradiance: UVB313 0.6W / m2 UVA340 0.68W / m2 Temperature range: RT 10 ~ 70 ?
UV accelerated aging test machine, UV light chamber details
1. Temperature range: RT 10 ~ 70 ?
2. Humidity range: greater than 90% RH
3. Sample and lamp distance: 50 ± 2mm
4. Distance between the centers of the tube: 70mm
5. Irradiance: UVB313 0.6W / m2 UVA340 0.68W / m2
6. Studio Size: 1170mm × 450 mm × 500 mm
7. Dimensions: 1300mm × 550 mm × 1380 mm
UV accelerated aging test machine security measures
1. Power overload, short circuit protection
2. Ground protection
3. Overtemperature protection
4. Water protection
5. Compression overvoltage, overload protection
6. To protect the device, all alarms are automatically cut off the power, and send voice prompts
UV accelerated aging test machine service commitments
1, free onsite installation, training of operators.
2, the product of one year from the date of delivery of repair kits to users, except in the following cases:
. A demand-side operational errors, malfunctions and damage to human;
b. by the supplier shall not bear other case
3, after the expiration of repair kits provide paid services.
