brand?Hui Yue science and technology
Model?HY-R09
Power Supply Voltage : 220V
principal axis?direction
Positive?apply
Wire diameter?0.03-0.4 (mm)
Step memory capacity : 1000
Product parameters:
Functions: the controller uses the latest synchronous with the lotus type cable, high accuracy, super high intelligent mode, with self detection function, including setting error, tracking speed and speed, with speeding detection function, can automatically lowered the spindle speed to the most stable state.
Wire diameter setting: 0-9.9mm
Cable distance: 0-100mm
Coil diameter: 80mm
The actual wire diameter: 1 axis 0.03-1; 2 axis, 4 axis 0.03-0.4 0.03-0.6; 3
1000 sets of memory settings
Spindle speed: 0-5000RPM
Motor: 1/2HP DC
Power supply: 50HZ 220V
Mechanical size: L620mm*W1000mm*H750mm (not included)
Weight: 62.5kg
Note: the spindle motor has: there is a brush, brushless, frequency conversion option; the other 1~4 axis option
