Description
HY-H11 dial semiautomatic tin soldering machine (economy) - parameters
Crest Number: None Drive Type: Pneumatic
Voltage and current: AC 220V Synonyms: Semi-automatic soldering machine
Pot temperature: 0-600 (?) Temperature control: thermostat
Starting power: 2 (KW) normal operating power: 2 (KW)
Dynamic forms: a cylinder Application: Solder
HY-H11 dial semiautomatic tin soldering machine (economy) - Performance
(1) Performance: ? Power supply voltage: AC 220V / 50Hz / 12A; ? tin furnace temperature: 0-600 ?; ? tin furnace material: Lead Free Titanium; ? tin furnace temperature control accuracy: ± 10 ? (typ. : 5 ?); ? tin furnace temperature control: PID control mode; ? Soldering time: 0.1Sec ~ 99.9Sec; ? tin furnace inner wall size: L200 * W90 * H40?; ? dimensions: L570 * W340 * H430?; ? Weight: 18KG.
(2) Characteristics: ? suitable for immersion tin variety of vertical, horizontal transformers and other components; ? can set the digital PID temperature control, temperature constant, the tin oxide surface is not easy; ? tin Furnace using titanium alloy, corrosion high temperature, durable (average service life of up to 5 years), non-stick tin tin good purity without impurities, especially suitable for lead-free solder; ? positioned vertically style fixtures, replacement quickly; ? heating rods is removable, easy to replace.
HY-H11 dial semiautomatic tin soldering machine (economic) Applicable products: high-frequency, low-frequency transformers, inductors, relays, filters, inductors, rectifiers, inductors.
