Using PLC control, Chinese touch screen interface, 5 axis AC servo motor drive system, positioning precision. Four stations around the line, the four station to be expected, unloading, can be set up a variety of winding way. Automatic indexing, winding, winding, winding pole changing, commutator hook, head and tail collection. Improve the production efficiency, reduce the loss of the wire, good product consistency.

Applicable models: from the M Series 7 Series 3 slot 5 slot 7 slot (or straight chute) motor.
Efficiency for example: 385# motor per pole 100 turns, about 1000pcs/H.
Main technical parameters:
Around the 4 station of the number of the +4 station to be expected to discharge, unloading
R axis of the highest speed 6000rpm, positive and negative can be
Adaptive wire diameter 0.05-----0.35mm
Counting precision +/-0.01 ring
Precision 0.01mm
Rotation angle accuracy of 0.1 degrees
Working pressure 46kg/cm2
Input power 220V/50Hz
Weight of whole machine 280kg
Outline dimension 600*1200*1300mm
