Y-Z03 Stator rotor vacuum oil immersion machine, automatic vacuum dipping paint processing equipment
Power supply: AC380V 50/60HZ
Power: 1HP
Inner cylinder volume: L705*W540*H300mm
Impregnation plate size: 220*660*30mm
Sub plate size: L675*W515*H105mm
Single cylinder size: L950*W660*H1160mm
Controller size: L500*W540*H1300mm
Impregnation machine: about length 2600x width 660x height 1300mm (about 450KG)

Standard impregnation machine height: about 80mm (can be customized according to customer requirements)
Features of vacuum dipping machine:
The vacuum dipping machine is a device suitable for dipping of high-frequency and low-frequency transformers, inductance coils, motors, inductors, rectifiers, metal castings and C-type iron cores.

It has the functions of improving the mechanical strength of the coil, insulating strength and moisture-proof, mildew-proof and noise reduction.
